WITH CE, SGS, TUV, BV Certificate
| Model | HL-150 (A~F) | HL-225 A~F. | HL-408A-F. | HL-800. | HL-1000. | ||||
| Interne afmetingen WxHxD (mm) |
500x600x500 | 600 x 750 x 500. | 600x850x800 | 1000x1000x800 | 1000x1000x1000 | ||||
| Externe afmetingen WxHxD (mm) |
1050 x 1750 x 1050 | 1200 x 1900 x 1150. | 1200x1950x1350 | 1600 x 2000 x 1450. | 1600x2100x1450 | ||||
| Temperatuurbereik | Low Temperature ((A:25oC B:0oC C:-20oC D:-40oC E:-60oC F:-70oC) Hoogte 150 graden. |
||||||||
| Vochtigheidsbereik | 20% R.H. ~ 98% R.H. (5% R.H. is optioneel) | ||||||||
| Analytic Accuracy/ Distribution Uniformity of Temperature | 0Een graden Celsius. | ||||||||
| Control Accuracy of Temperature | ± 0,5 °C | ||||||||
| Temperatuur stijging/ Afnemende snelheid |
Temperatuur stijging van ongeveer 0,1 tot 3,0 °C/min; Temperatuur dalen approx. 0.3~1.0oC/min; (Faster change rate is optional) |
||||||||
| Intern en extern. Materiaal |
Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel of SEE cold-rolled steel with paint coated. | ||||||||
| Isolatie materiaal |
Resistent tegen hoge temperatuur, hoge dichtheid, formeel chloor. Ethyl acetum foam isolatiematerialen |
||||||||
| Koelsysteem | Windgekoeld of watergekoeld, single segment compressor voor -40oC, double segment compressor voor -70oC | ||||||||
| Beschermingsmiddelen | Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, Over-humidity and over-temperature protection switch, fuses, fault warning system | ||||||||
| Optioneel accessoire | Inner door with operation hole (Optional), Recorder (Optional), Dehumidifier | ||||||||
| Compressor | Frans Tecumseh Brand, Duits Bizer Brand. | ||||||||
| Kracht | AC 220V, 1 phase 3 Lines,50/60HZ; AC 380V,3 phase 5 Lines,50/60HZ | ||||||||
| Gewicht (kg) | 180 | 250 | 320 | 400 | 450 | ||||
